toysim user manual
| Title | toysim (ArchC functional simulator for the Princeton TOY machine) |
| Author | Nikolaos Kavvadias 2010, 2011, 2012, 2013, 2014 |
| Contact | nikos@nkavvadias.com |
| Website | http://www.nkavvadias.com |
| Release Date | 02 December 2014 |
| Version | 0.0.4 |
| Rev. history | |
| v0.0.4 | 2014-12-02 Added project logo in README. |
| v0.0.3 | 2014-11-02 Documentation corrections. |
| v0.0.2 | 2014-10-30 Project cleaned-up and updated for Github. |
| v0.0.1 | 2010-12-11 First public version. |
1. Introduction
This is the ArchC (http://www.archc.org) functional simulator model for the Princeton TOY processor. The Princeton TOY machine is a 16-bit educational RISC processor with only two orthogonal encodings. A description of the basic ISA is available in the form of the TOY reference card.
This model has the system call emulation functions implemented, so it is a good idea to turn on the ABI option. It should be noted that this capability is currently untested.
2. File listing
The toysim distribution includes the following files:
| /toysim | Top-level directory |
| AUTHORS | List of toysim authors. |
| LICENSE | The modified BSD license governs toysim. |
| README.html | HTML version of README. |
| README.pdf | PDF version of README. |
| README.rst | This file. |
| VERSION | Current version of the project sources. |
| defines_gdb | Macro definitions for GDB integration. |
| modifiers | Instruction encoding and decoding modifiers. |
| rst2docs.sh | Bash script for generating the HTML and PDF versions of the documentation (README). |
| run_tools.sh | Script for automating the build of the simulator and the associated binary utilities (binutils) port. |
| toy.ac | Register, memory and cache model for TOY. |
| toy_gdb_funcs.cpp | GDB support for the TOY simulator. |
| toy_isa.ac | Instruction encodings and assembly formats. |
| toy_isa.cpp | Instruction behaviors. |
| toy_syscall.cpp | OS call emulation support for TOY (untested). |
| toysim.png | PNG image for the toysim project logo. |
| /tests | Tests subdirectory |
| run-tests.sh | Run a selected benchmark. |
| /fibo | Fibonacci series benchmark directory |
| Makefile | Makefile for building the benchmark. |
| ac_start.s | Startup file (prior main()) for TOY. |
| fibo.asm | Fibonacci benchmark using the alternative Princeton TOY assembly syntax (defined for the ArchC model). |
| /popcount | Population count benchmark directory |
| Makefile | Makefile for building the benchmark. |
| popcount.asm | Population count benchmark using the original assembly syntax (needs to be converted). |
3. Usage
To generate the interpreted simulator, the acsim executable is ran:
$ acsim toy.ac [-g -abi -gdb] # (create the simulator) $ make -f Makefile.archc # (compile) $ ./toy.x --load=<file-path> [args] # (run an application)
To generate the compiled application simulator, the accsim executable is ran:
$ accsim toy.ac <file-path> # (create specialized simulator) $ make -f Makefile.archc # (compile) $ ./toy.x [args] # (run the application)
The [args] are optional arguments for the application.
There are two formats recognized for application <file-path>:
- ELF binary matching ArchC specifications
- hexadecimal text file for ArchC
In order to generate the binary utilities port (binutils port), the acbingen.sh driver script must be used. This should be called as follows:
$ acbingen.sh -atoy -i`pwd`/../toysim-tools/ toy.ac
for generating the binutils port executables. This includes the following tools:
- addr2line
- ar
- as
- c++filt
- gdb (the GDB port is also generated in the same directory)
- gdbtui
- ld
- nm
- objcopy
- objdump
- ranlib
- readelf
- size
- strings
- strip
4. Notes
The assembly instruction syntax followed by the ArchC-based simulator for TOY is quite different than the original syntax. The following table summarizes the differences of the two syntax variations.
| Original syntax | ArchC-compatible syntax |
| R[d] <- imm8 | lda rd, imm8 |
| R[d] <- mem[imm8] | ld rd, imm8 |
| R[d] -> mem[imm8] | st rd, imm8 |
| R[d] <- mem[R[t]] | ldi rd, rt |
| mem[R[t]] <- R[d] | sti rd, rt |
| R[d] <- R[s] + R[t] | add rd, rs, rt |
| R[d] <- R[s] - R[t] | sub rd, rs, rt |
| R[d] <- R[s] & R[t] | and rd, rs, rt |
| R[d] <- R[s] ^ R[t] | xor rd, rs, rt |
| R[d] <- R[s] << R[t] | shl rd, rs, rt |
| R[d] <- R[s] >> R[t] | shr rd, rs, rt |
| R[d] <- pc; pc <- imm8 | jal rd, imm8 |
| pc <- R[d] | jr rd |
| if (R[d] == 0) pc <- imm8 | jz rd, imm8 |
| if (R[d] > 0) pc <- imm8 | jp rd, imm8 |
| pc <- pc | halt |
Supported pseudo-instructions include:
- nop (no operation)
- move (move register)
- neg (negate)
- li (load immediate)
- la (load address)
5. Prerequisites
- ArchC installation (tested on Cygwin/Win7-64bit and Linux)
- Standard UNIX-based tools: make, gcc.
